86
Refrigeration
Foam-Edge Gaskets
Applications
• Insulating
• Sound proofing
• Shock absorber
• Light seal
• Dirt seal
Description
• Soft flexible polyurethane foam core
covered with a thin vinyl sheeting
Foamedge Gaskets
Part #
Length
Cushion
Diameter
Flange
Width
81-3703-100
100'
3/8"
3/8"
81-5005-100
100'
1/2"
1/2"
81-6206-100
100'
5/8"
5/8"
81-7507-100
100'
3/4"
3/4"
81-5005-100
Illustrated
Gaskets
V Series V-Line Gaskets
• Closed cell sponge rubber interior with flexible vinyl
flange & outer covering.
• Resists oils, greases, fats, detergents, water.
• Will not deteriorate in hot or cold weather.
• Won’t crack, check or oxidize.
Offset
Flange
Regular
Flange
Applications
• Walk in coolers
• Weather exposed
freezer doors
• Refrigerated trucks
• Railroads
Regular Flange
Part #
Length
Cushion
Diameter
Flange
Width
Overall
Width
81-V1212-25
25'
1/2"
1/2"
1"
81-V1212-100
100'
81-V3812-25
25'
3/8"
1/2"
7/8"
81-V3812-100
100'
81-V5858-25
25"
5/8"
5/8"
1 1/4"
81-V5858-100
100'
Offset Flange
Part #
Length
Cushion
Diameter
Flange
Width
Overall
Width
81-V1234-25
25'
1/2"
3/4"
1 3/16"
81-V1234-100
100'
1/2"
3/4"
1 3/16"
81-V1234-100
Illustrated
Regular
Flange
Inner Seal Gaskets
NX Series Inner Seal Gaskets
• Sponge rubber cushion with reinforced rubber covered
woven galvanized wire flange.
• Flange extends into cushion minimizing chance of
cushion being torn away. Entire gasket coated in a
protective polyurethane coating.
Applications
• Locker plants
• Refrigerated trucks
• Railroad
• Marine
• Industrial
NX Inner Seal Gasket
• Polyurethane coated.
Part #
Length
Cushion
Diameter
Flange
Width
Overall
Width
81-NX302-100
100'
3/8"
1/2"
7/8"
81-NX402-100
100'
3/8"
3/4"
1 1/8"
81-NX502-100
100'
1/2"
1/2"
1"
81-NX504-100
100'
1/2"
3/4"
1 1/4"
NX Regular
Flange
NX Series
Gaskets
Illustrated
Gaskets
