99
Heating & A/C
Pipe Mounted
• Replaces industrial glass "mercury"
thermometers stem assembly.
Part #
Description
14-DVU35
3 1/2" Industrial Stem
14-DVU6
6" Industrial Stem
Duct Mounted
• Replaces bimetal dial thermometers
stem assembly.
Part #
Description
14-DVBM25
2 1/2" x 1/2" NPT Stem
14-DVBM4
4" x 1/2" NPT Stem
14-DVBM6
6" x 1/2" NPT Stem
14-DVD6
6" Stem w/ Duct Mtg. Flange
14-DVD9
9" Stem w/ Duct Mtg. Flange
Vari-Angle Thermometers
The Weiss patented, Digital Vari-angle
®
Thermometer maintains the strict requirements for thermometers
in hydronic applications in that they are self-powered to within 1% accuracy. This reliable series of digital
thermometers offers the added feature of stem assemblies for direct replacement of mercury-in-glass types where
environmental concerns exist. Whether on new installations or replacements, the Vari-angle Digital Thermometers
include the same level of quality that the industry associates with the Vari-angle trademark and all Weiss products.
Insert Well Stems Adapters
Part #
Description
14-E35*
3/4" NPT 3 1/2" Socket
14-ER6*
3/4" NPT 6" Socket
14-EN6*
3/4" NPT 6" Ext. Socket
* For use with DVU thermometers on new installations.
Vari-Angle Digital Thermometers - Solar Powered
Specifications
(Pipe & Duct Vari-Angle Thermometer )
• Case: Hi-impact ABS.
• Range: -45 to 150°C (-50 to 300°F).
• Display: 1/2" LCD digits, wide ambient formula.
• Accuracy: 1% of reading or 1° whichever is
greater.
• Resolution: 1/10° between -28 to 93°C (-19.9 to
199.9°F).
• Recalibration: Internal potentiometer.
• Lux Rating: 10 Lux (one foot-candle).
• Update: 10 seconds.
• Ambient Operating: -35 to 60°C (-30 to 140°F).
• Ambient Temp Error: Zero.
• Humidity: 100%.
• Sensor: Glass passivated thermistor.
• Stem Assemblies:
Industrial Glass
• Full Conformance with Fed Spec GG-T-321D.
• Fully interchangeable with Industrial Glass
Thermometers.
Bimetallic
• Full conformance with ASME B40.3-1990.
• Fully interchangeable with Bimetallic Dial
Thermometers.
14-DVU35
Illustrated
14-DVD6
Illustrated
14-E35
Illustrated
14-DVC-4
Outdoor Cover
Accessories
Part #
Description
14-DVC-4
Outdoor Waterproof Cover
Range: -45 to 150°C
(-50 to 300°F).
Thermometers
