Service Tools
All PRO-SET® Machines!
• On the fly self-clearing valve (except 46-CR300).
• Integrated manifold block system.
• Built-in suction filter located under the suction port.
• Indestructible high-density polyethylene case.
• Comfortable integrated carrying handle.
• Worldwide approvals - CSA, CE, TUV-GS.
• UL certified to meet or exceed EPA regulations per ARI standard 740-95.
46-CR500
Illustrated
46-CR600
Illustrated
46-CR400
Illustrated
Refrigerant Recovery Machines
Applications
• Appliances
• Small A/C units
• Automobiles
Applications
• Residential A/C
• Commercial
Applications
• Appliance
• Residential A/C
• Light Commercial
R410A
Compatible
R410A
Compatible
R410A
Compatible
Oil Filled Refrigerant Recovery Machines - PRO-SET®
Part #
Features
Specifications
46-CR300
46-CR310
Includes 80%
overfill sensor
cord.
• R410A Ready!
• Economical recovery workhorse.
• Heavy-duty oil filled compressor.
• Simple, easy-to-use design.
• Built-in suction filter.
• 46-CR300A (230V Model)
Capacity
• Direct Vapour: 6kg/hr (0.22lbs/min).
• Direct Liquid: 19.8kg/hr (0.73lbs/min).
• Push-Pull Liquid: 282kg/hr (10.38lbs/min).
Mechanics
• Compressor: 1/6HP Hermetic.
• Voltage: 110VAC 50/60hz.
• Weight: 12.6kg (28lbs).
46-CR400
46-CR410
Includes 80%
overfill sensor
cord.
• R410A Ready!
• Fully automatic liquid or vapour recovery.
• Advanced rifled tube lance fin condenser.
• 550 PSI high pressure cut-off switch.
• Extremely quiet operation.
• 46-CR400E (230V Model).
Capacity
• Direct Vapour: 6kg/hr (0.22lbs/min).
• Direct Liquid: 19.8kg/hr (0.73lbs/min).
• Push-Pull Liquid: 282kg/hr (10.38lbs/min).
Mechanics
• Compressor: 1/6HP Hermetic.
• Voltage: 110VAC 50/60hz.
• Weight: 12.6kg (28lbs).
Oil-Less Refrigerant Recovery Machines - PRO-SET®
Part #
Features
Specifications
46-CR500
46-CR510
Includes 80%
overfill sensor
cord.
• R410A Ready!
• Lightest recovery unit in its class! Only
19.5lbs.
• Fast recovery of liquid or vapour refrigerant.
• Advanced rifled tube lance fin condenser.
• Fast recovery of liquid or vapour.
• 550 PSI high pressure cut-off switch.
• 46-CR500E (230V Model)
Capacity
• Direct Vapour: 10.3kg/hr (0.38lbs/min).
• Direct Liquid: 82.3kg/hr (3.03lbs/min).
• Push-Pull Liquid: 332kg/hr (12.22lbs/min).
Mechanics
• Compressor: 1/3HP Oil-Less.
• Voltage: 110VAC 50/60hz.
• Weight: 9.0kg (20lbs).
46-CR600
46-CR610
Includes 80%
overfill sensor
cord.
• R410A Ready!
• Fully automatic liquid or vapour recovery.
• Advanced rifled tube lance fin condenser.
• "Super Cool" dual fan cooling system
enables unit to operate in 60°C (140°F).
desert heat!
• 550 PSI high pressure cut-off switch.
• 46-CR600E (230V Model).
Capacity
• Direct Vapour: 10.3kg/hr (0.38lbs/min).
• Direct Liquid: 70.6kg/hr (2.60lbs/min).
• Push-Pull Liquid: 317kg/hr (11.66lbs/min).
Mechanics
• Compressor: 1/2HP Oil-Less.
• Voltage: 110VAC 50/60hz.
• Weight: 13.1kg (29lbs).
Recovery Machines
