263
Service Tools
46-AD12
Illustrated
46-AD48
Illustrated
46-AD81
Illustrated
46-AD14
Illustrated
R134A Tank, Coupler & Vacuum Pump Adapters
Part #
Description
Applications
46-AD12
1/2" ACME female × male low side R134a.
R134a automotive tank
adapter.
46-AD14
14mm male × 1/4" male SAE.
R134a automotive coupler
adapter.
46-AD48
1/4" SAE female × 1/2" Acme male (3/pk).
Includes cores.
Manifolds, hoses, tanks,
recovery & vacuum pumps)
46-AD81
3/4" 14 SAE female × 1/2" Acme male.
125 lb. tank adapter.
Automotive Adapters
R12 90° & Straight Adapters
Part #
Description
Applications
46-ADGM
GM deep reach female × 1/4" SAE.
Includes extended core depressor.
GM R12 posiseal Hi-side
91-94.
46-AD18C
Straight 1/8" SAE female × 1/4" SAE
male. Includes core & depressor.
R12 automotive Hi-side.
46-AD36C
Straight 3/16" SAE female × 1/4" SAE
male. Includes cap & core.
R12 automotive Hi-side.
46-AD149C
90° 1⁄4 SAE female" × 1/4" SAE male.
Includes core & depressor.
Hard to access ports.
46-AD369C
90° 3/16" SAE female × 1/4" SAE male.
Includes cap & core.
R12 automotive Hi-side.
46-ADGM
Illustrated
46-AD18C
Illustrated
46-AD36C
Illustrated
46-AD149C
Illustrated
46-AD369C
Illustrated
Automotive
Adapters
Fitting Adapters
Part #
Description
Applications
46-AD24
1/4" SAE male × 1/8" MNPT (6/pk).
1⁄4" service manifold adapter.
46-AD41
3/4" 14 SAE female × 1/4" SAE male.
Large 125lb cylinders.
46-AD44
1/4" SAE male × 1/4" MNPT adapter
(6/pk). Includes caps & cores.
Vacuum pumps.
46-AD47
1/4" SAE male × 1/4" SAE male union. 1/4" hose union.
46-AD48
1/4" SAE female × 1/2" Acme male
(3/pk). Includes cores.
Manifolds, hoses, tanks,
recovery & vacuum pumps.
46-AD68
1/2" ACME female × 3/8" SAE male
(3/pk).
Vacuum pumps.
46-AD78
1/4" SAE female × 1/2" 20 UNF male.
Includes core & depressor.
R410A international -
manifolds, hoses, tanks,
recovery & vacuum pumps.
46-AD81
3/4" 14 SAE female × 1/2" Acme male . 125 lb. tank adapter.
46-AD84
1/2" Acme female × 1/4" SAE male
(3/pk).
Manifolds, hoses, tanks,
recovery & vacuum pumps.
46-AD849C
90° 1/2" Acme female × 1/4" SAE male
(3/pk). Includes core.
Manifolds, hoses, tanks,
recovery & vacuum pumps.
46-AD87
1/2" 20 UNF female × 1/4" SAE male.
Includes core & depressor.
R410A international -
manifolds, hoses, tanks,
recovery & vacuum pumps.
Fitting Adapters
46-AD41
Illustrated
46-AD81
Illustrated
46-AD48
Illustrated
46-AD78
&
46-AD87
Illustrated
R410A
Compatible
46-AD24
Illustrated
46-AD47
Illustrated
46-AD44
Illustrated
46-AD68
Illustrated
Adapters & Fittings
