Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Ventilation Motors & Fan Kits
Motor
Part #
Fig.
Blower
Part #
Fig.
HP Amps RPM CFM Shaft
Bracket # Blower # Dia. Width Bore Rot.
O6-R261
5
-
-
1/200
0.31 1/1550 77 1.75"×5/16"
O6-R260
5
R7-RB22
1
1/90
0.60 1/1550 75 1.10"×5/16"
92-A8602 66-A508202
5 1/16"
2"
5/16" CCW
O6-R265
5
-
-
1/90
0.65 1/1400 115 1.60"×5/16"
O6-R264
6
R7-RB26
1
1/75
0.70 1/1550 141 2.00"×5/16"
92-A8604 66-A610215
6 1/16" 2 5/32" 5/16" CCW
O6-R267
5
-
-
1/50
0.85 1/1550 118 1.50"×5/16"
O6-R262
5
R7-RB24
R7-RB25
1
1
1/40
1.10 1/1550
116
130
1.80"×5/16"
92-A8602 66-A508216
5 1/16" 2 5/32" 5/16" CCW
T1-R630
4
R7-RB20
2
1/35
0.76 1/1550 60 1.90"×7/32"
92-A8600 93-A7105
5"
1 1/8" 7/32" CCW
M3-R2602
7
R7-RB29
3
1/35
1.15 1/1550 268 2.20"×1/2"
92-A8606 66-A610220
6 1/16" 2 5/32" 1/2" CW
M3-R2603
7
R7-RB30
3
1/35
1.15 1/1550 268 2.20"×1/2"
92-A8606 66-A610220
6 1/16" 2 5/32" 1/2" CW
O6-R266
6
R7-RB28
1
1/20
1.45 1/1550 201 1.40"×5/16"
92-A8604 66-A610215
6 1/16" 2 5/32" 5/16" CCW
M4-R2605
7
-
-
1/12
3.00 1/1050 450 1.60"×1/2"
M3-R2604
7
-
-
1/10
2.87 1/1550 300 2.00"×1/2"
Figure 4
Figure 5
Figure 6
Figure 7
R630
R262
R260
R261
R265
R267
R264
R266
R2605
Figure 2
Figure 3
Figure 1
RB20
RB24
RB22
RB25
RB26
RB28
A7105
A610215
RB30
RB29
Blower
Wheels
Cross Reference
Motor Part # Blower Part #
Cross Reference
T1-R630
R7-RB20
013005, EB50
O6-R260
R7-RB22
B60, 013012, EB60, 4099
O6-R261
-
QB60-80
O6-R262
R7-RB24
R7-RB25
B100, K100, 013011, 4105
O6-R264
R7-RB26
QK100, 013020
O6-R265
-
QB100
O6-R266
R7-RB28
BK100, 013024, 4115
O6-R267
-
BB-100, 013019
M3-R2602
R7-RB29
SAME AS RB30 BUT OPPOSITE ROTATION
M3-R2603
R7-RB30
DK260, DB200, FRANKLIN 75003, 013041, 013040, 4143
M3-R2604
-
DB300, 013062, 013042
M4-R2605
-
QBD300
