44
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
ROTOM® is a registered trade marks of ALLTEMP® PRODUCTS COMPANY LIMITED.ALLTEMP® has made an effort to illustrate with photos, outline drawings and/or descriptions, the products in this catalogue.These
are for thesolepurposeof identification.Wedonotexpressor imply thatproductsconformexactly to thedescriptions,drawingsand/orphotos.Allreasonableefforthasbeenmade toaccuratelydetermineasuitableproduct.
However,allusersaresolelyresponsible toevaluateanddetermine for themselves thesuitabilityof theproductpurchased for theuse intended.All information,dataanddimension tables in thiscataloguehavebeencarefully
compiled and thoroughly checked.However, no responsibility for possible errors or omissions can be assumed.The company reserves the right to change specifications and other information included in this catalogue
without notice.The vendor’s responsibility shall be limited only to its written warranty and the vendor shall not be responsible for any loss, cost or damage whatsoever from the use of this product by you or your customers.
Part #
Amps Watts Duct Dia.
Volts
Hz
CFM
T9-TF104
0.53
40
4"
115
60
200
T9-TF106
1.00
70
6"
115
60
409
T9-TF108
1.70 120
8"
115
60
650
Part #
Diameter
Length
T9-DM105
5"
24"
T9-DM106
6"
24"
T9-DM108
8"
24"
T9-DM110
10"
36"
T9-DM112
12"
36"
Features
• High Volume & Pressure
• Installs In Any Position
• Ball Bearings Are Permanently
Sealed & Lubricated
• Backwards Inclined Blades
• Vibration Absorbing Material
• Class B TP Auto Reset
• UB Protected / Flame Retardant -
Thermal Plastic Resin
• 140°F(60°C) Maximum Air Stream
Temperature
Accessories
• Speed Control
• Power Cord
• Auto Switch
• Duct Mufflers
Applications
• Ventilation
• Exhaust
• In-Line Boosting
• Radon Mitigation
• Dryer Vent Boosting
In-Line Air Duct Booster Fans
™
5 YEAR
LIMITED
Warranty
Serious Air Power With Quiet Operation
Cat # ROT072512
In-line Duct Boosters
Duct Muffler
