SECTION
PAGE
DATE
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598 A Crane Co. Company
Sump Pumps
13
A
www.cranepumps.com
Professional Plumbing
8/06
Series UT17
Portable Utility - 1/8" Spherical Solids Handling
Manual - Submersible
DISCHARGE ............................... 3/4" G.H.T. Male, Vertical
LIQUID TEMPERATURE .............77°F (25°C) Continuous
MOTOR HOUSING .....................Thermoplastic
PUMP STRAINER........................Thermoplastic
IMPELLER: Design ....................2 Vane, Semi-open
Material ..................Thermoplastic
SHAFT ........................................Steel
O-RINGS ................................Buna-N
HARDWARE ................................Stainless Steel
SEAL: Design ....................Single Mechanical, Type 6
Material ................... Carbon/Ceramic/Buna-N
CORD ENTRY..............................15 ft. (4.5m) Cord with plug and pressure
Gromment for sealing and strain relief
UPPER BEARING........................Single Row, Ball, Oil Lubricated
LOWER BEARING.......................Single Row, Ball, Oil Lubricated
MOTOR Design..................... Air-Filled
Insulation................. Class B
SINGLE PHASE...........................Permanent Split Capacitor (PSC).
Includes Thermal Overload Protection
in Motor Series: UT17
1/6 HP, 3450RPM, 60Hz
DESCRIPTION:
GENERAL PURPOSE PUMP FOR RESIDENTIAL AND
LIGHT INDUSTRIAL SUMP APPLICATIONS
Testing is performed with
water specific gravity of 1.0
@ 68˚F (20˚C), other fluids
may vary performance
CSA 108
UL 778
LR16567
C US
