50
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Part # HP Volts Amps Type RPM Rot. Body FrameBearing Cap Shaft
Comments
Fig
M4-R2197
1/14
115 1.25
PSC 3/820 CCW 3.8" 5.0" Sleeve 7.5/370 3.4"×1/2"
DE3E142N
1
M4-R2198
1/14
115 1.25
PSC 3/820 CCW 3.8" 5.0" Sleeve 7.5/370 3.4"×1/2"
DE3E142N
2
M4-R2194
1/14
115 1.25
PSC
3/820 CCW 4.0" 5.0" Sleeve 7.5/370 3.4"×1/2"
DE3E141N
3
M4-R2195
1/12
115 2.10
PSC
3/740 CCW 4.6" 5.0" Sleeve 7.5/370 3.4"×1/2"
DE3F056N
3
M4-R2196
1/8
115 2.50
PSC
3/850 CCW 4.5" 5.0" Sleeve 7.5/370 3.9"×1/2"
DE3G110N
3
UE-799
1/8
115 2.60
PSC
5/1075 CCW 3.75" 5.0" Sleeve 5/370 5.0"×1/2"
L350,L450,L600, UE DA3E200,
DA3F100, DA3G142
3
Trane (cont. next page)
Temspec
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap
Shaft
Comments Fig
UE-641
1/30
115
0.5 PSC 3/1075 CW 3.5" 5.0" Sleeve
Inc.
8.5"×1/2"×9"
MOT 1876, CX70500133-
01, UE DE3E152
4
UE-954
1/30
115
0.6 PSC 3/1100 CW 4.0" 5.0" Sleeve
Inc.
8.5"×1/2"
MOT 1878, MOT 1875,
X70500149-01-7, EM
K48HXBYH-954
5
UE-952
1/30
115
0.74 PSC 3/1100 CW 3.75" 5.0" Sleeve
Inc.
8.5"×1/2"×9"
EM K48XBJP-969,
X70500149-03-7,
MOT-1876
4
UE-373
1/30
115
0.64 PSC 2/1100 CW 4.25" 5.0'
Sleeve
Inc.
10.5"×1/2"×10.5
Fan Coil
6
UE-9447
1/30
208/230 0.60 SP 1/3000 CW 5.5" 3.3"
Ball
-
Blower
7021-7833, FASCO A150
7
UE-372
1/25
115
0.64 PSC 2/1060 CW 3.5" 5.0" Sleeve
Inc.
11"×1/2"×11"
Fan Coil
6
UE-9608
1/20
115
0.6 PSC 3/1100 Rev 3.25" 5.0" Sleeve
Inc.
9.5"×1/2"
MOT 1875, X70500149-02,
EM K48HXBHZ955
5
UE-953
1/15
115
0.8 PSC 3/1100 CW 3.25" 5.0" Sleeve
Inc.
10.5"×1/2"×10.5"
MOT 1877, X70 500149-04-
7, EM K48HXBJA-956
8
UE-964
1/15
115
0.85 PSC 1/3400 CCW 4.67" 3.3"
Ball
3/370
1.5"×1/2"
44471, JF1F059
9
UE-680A
1/8
115
1.50 PSC 3/775 CCW 5.0" 5.5" Sleeve
Inc.
11.5"×1/2"×11.5"
MOT-711
4
UE-598
1/8
230
1.90 SP 1/1550 CCW 4.25" 5.0" Sleeve
-
3.0"×1/2"
5KSP29DK1728S
10
UE-945
1/8
115
1.2 PSC 3/1500 CW 4.0" 5.0" Sleeve
Inc.
9"×1/2"×7.5"
MOT 1978, MOT 481, X70
500149-11-7,
EM K48HXCKT-1419
8
UE-492
1/8
230
1.10 PSC 1/1550 CCW 3.5" 5.0" Sleeve
Inc.
3.0"×1/2"
5KSP29DK1728S
11
M2-R31673
1/8
200/230 0.90 PSC 1/1650 CCW 3.62" 5.5" Sleeve 4/370
1.5"×1/2"
3D149098P01, 1673
K55DJK-6905
12
M4-R1050
1/4
208/240 0.90 PSC 1/1550 CCW 3.37" 5.0" Sleeve
Inc.
3.18"×1/2"
D1050, 3438,
5KSP29DK1728S, 322P815
13
Fig. 4
Fig. 3
Fig. 2
Fig. 1
Fig. 8
Fig. 5
Fig. 6
Fig. 7
Fig. 9
Fig. 10
Fig. 11
Fig. 12
Fig. 13
OEMReplacementMotors
"N" - New Product
