Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
Reversomatic
Reversomatic Motors &
Blowers & Components
Reversomatic Ventilation Fan Motors & Kits
Exhaust Fan Motors, Blowers, Brackets & Wheels
• 115 Volt
• Shaded Pole
• CW Rotation
• Blowers include motor, bracket & blade.
Motor
Part #
Fig.
Blwr.
Part #
Fig.
HP Amps RPM CFM Shaft
Bracket # Blower # Dia. Width Bore Rot.
R630
4
RB20
1B 1/35 0.76 1/1550 60 1.90"×7/32"
A8600
A7105
5"
1 1/8" 7/32" CCW
R260
5
RB22
2B 1/90 0.60 1/1550 75 1.10"×5/16"
A8602 A508202
5 1/16"
2"
5/16" CCW
R261
5
-
-
1/200 0.31 1/1550 77 1.75"×5/16"
R262
5
RB24
RB25
2B
2B
1/40 1.10 1/1550
116
130
1.80"×5/16"
A8602 A508216
5 1/16" 2 5/32" 5/16" CCW
R264
6
RB26
2B 1/75 0.70 1/1550 141 2.00"×5/16"
A8604 A610215
6 1/16" 2 5/32" 5/16" CCW
R265
5
-
-
1/90 0.65 1/1400 115 1.60"×5/16"
R266
6
RB28
2B 1/20 1.45 1/1550 201 1.40"×5/16"
A8604 A610215
6 1/16" 2 5/32" 5/16" CCW
R267
5
-
-
1/50 0.85 1/1550 118 1.50"×5/16"
R2602
7
RB29
3B 1/35 1.15 1/1550 268 2.20"×1/2"
A8606 A610220
6 1/16" 2 5/32" 1/2"
CW
R2603
7
RB30
3B 1/35 1.15 1/1550 268 2.20"×1/2"
A8606 A610220
6 1/16" 2 5/32" 1/2"
CW
R2604
7
-
-
1/10 2.87 1/1550 300 2.00"×1/2"
R2605
7
-
-
1/12 3.0 1/1050 450 1.60"×1/2"
Figure 4
Figure 5
Figure 6
Figure 7
R630
R262
R260
R261
R265
R267
R264
R266
R2605
Figure 2B
Figure 3B
Figure 1B
RB20
RB24
RB22
RB25
RB26
RB28
A7105
A610215
RB30
RB29
Blower
Wheels
Comment
Motor Part # Blower Part #
Comment
R630
RB20
013005, EB50
R260
RB22
B60, 013012, EB60
R261
-
QB60-80
R262
RB24
RB25
B100, K100
R264
RB26
QK100, 013020
R265
-
QB100
R266
RB28
BK100, 013024
R267
-
BB-100, 013019
R2602
RB29
SAME AS RB30 BUT OPPOSITE ROTATION
R2603
RB30
DK260, DB200, FRANKLIN 75003, 013041, 013040
R2604
-
DB300, 013062
R2605
-
QBD300
