Accessories
For motors with Catalogue Numbers 092000–140999
C Face Kit
App. Wgt.
Frame
Enclosure
Catalogue Number
(lbs.)
42
Open / Enclosed
175661
2
48
Open / Enclosed
175969
M
2
Open / Enclosed
175646
Ø
2
S56
Open
175000
2
Enclosed
175180
2
Open / Enclosed
175297
W
2
Open / Enclosed
175647
Ø
2
56
Open
175075
2
Enclosed
175076
2
Severe Duty
175078
5
(see note 2) Enclosed
M064076
S
2
143T-145T Open
175181
2
Enclosed
175077
2
Enclosed
M064077
S
2
182T-184T Open / Enclosed
175691
$
2
182T-184T
Open / Enclosed
175294
5
Special
"
S213T
Open / Enclosed
175693
$
2
213T-215T Open
175009
19
(1750 RPM) Open
175845
:
19
Enclosed
175010
15
Enclosed
175844
:
15
213T-215T ODP
175303
.
15
(3450 RPM) Enclosed
175304
.
15
NOTE:
1) When changing a rigid mount motor to C Face for 140T-256T frames,
a non-NEMA BA dimension results. e.g. M009090
2) Some larger HP 56-frame motors have larger shaft-end bearings and
require a 143T-145T C Face kit. Contact LEESON.
C Face Kit
App. Wgt.
Frame
Enclosure
Catalogue Number
(lbs.)
182T-184T
Enclosed
175805
¡
12
213T-215T
Enclosed
175869*
14
324T-326T
Open
175454
57
364T-365T
Open
175601
¨
75
Enclosed
175603
¨
75
*Locked bearing
SHADED FRAME INDICATES CAST IRON CONSTRUCTION
NEMA C FACE KITS
STEEL FRAME MOTORS
Includes parts to convert a rigid base mounted
motor to NEMA C face with base.
The C Face Kits
cannot
be used as replace-
ments on a factory-produced C face motor.
NEMA C FACE KITS WATTSAVER
®
MOTORS
Special conversion kits for use exclusively on WATTSAVERe
®
cast iron
frame motors.
NEMA C FACE KITS
CAST IRON MOTORS
Includes parts to convert a rigid base mounted
motor to NEMA C face with base.
The C Face Kits
cannot
be used as replace-
ments on a factory-produced C face motor.
* Not suitable for 2 pole motors
h
:
Use these kits for new-design 213T and 215T motors that have external thru-bolts
$
Use this kit for 182-4T and S213T motors with catalogue numbers 131454 and higher, or with a G prefix.
Both open and enclosed motors in this series use the same kits as ventilation is in the frame of the motor.
Not TS Frame.
For older cast iron motors with date code C93 or earlier.
W
For use with motors having “P” suffix on date code.
"
Converts a 182T-184T frame motor to the C-face dimensions of a 143T-145T or 182U184U frame motor --
AJ = 5
7
⁄
8
”
,
AK = 4
1
⁄
2
”. Does not change the shaft extension or BA dimension to match the other frame sizes.
.
For use with 3450 RPM, 213T-215T (213JP-215JP) motors only.
S
For use with Industry-Ag motors only.
M
For use with AC motors having “P” suffix on date code. Results in non-NEMA shaft and BA dim.
?
Not for use with WATTSAVERe
®
motors.
¨
WATTSAVER II design, having oversized frame body.
¡
For use with motors having date codes May 2003 and later.
Æ
Not for modifying stock motors.
Ø
For motors manufactured after January 1, 2007, having a “B” suffix letter after the motor’s
∞
For 3450 RPM motors use WATTSAVER
®
kit 175805
±
For 3450 RPM motors
MOTOR ACCESSORIES
C FLANGE KITS
For 150 Series and 170 Series Cast Iron Motors Only
C Face Kit
App. Wgt.
Frame
Enclosure
Catalogue Number
(lbs.)
143T-145T
Enclosed
163116
10
182T-184T
Open
163046
Æ
12
Enclosed
175655
∞
12
213T-215T
Open
175066
14
Enclosed
175068
14
254T-256T
Open
163018
25
Enclosed
163031
25
284T-286T
Open
163019
42
Enclosed
163015
42
324T-326T
Open
163020
57
Enclosed
163016
57
364T-365T
Open
163021
75
Enclosed
163017
75
404T-405T
Open
163097
80
Enclosed
163033
80
444T-445T
Open
163094
100
Enclosed
163040*
100
444TS-445TS Enclosed
163124
±
100
447T-449T
Enclosed
163093
140
447TS-449TS Enclosed
163137
±
140
NOTE:
When changing a rigid mount motor to “C” Face for 213T, 215T, 254T and 256T frames,
a non-NEMA BA dimension results.
