phone: 1-800-678-7178 fax: 1-800-270-9342
- 52 -
Central Spa
&
Pool Supply Ltd.
© 2012
SKU Number
List Price Code Description
S
PA
H
EATERS
RAYPAK ELECTRIC HEATER
The Raypak Electric Spa Heater consists of a sheathed low watt density resistance element
installed in a copper tank. This tank has a 1-1/2” threaded inlet and outlet on the side for plumbing
connection. The heater voltage is only 240V single phase. The control circuit passes through a
manual switch, the temperature control and magnetic contactor coil. All items are pre-wired and
installed in a baked enamel steel case. Available in two compact models 5.5KW and the 11KW.
RAYPAC 5.5 KW
$ 1,195.00
A
5.5 KW Electric Heater
RAYPAC 11 KW
$ 1,321.96
A
11 KW Electric Heater
RAYPAK PARTS
ELE-55F-R
$ 274.42
B
5.5 KW Element
ELE-11F-R
$ 299.38
B
11 KW Element
600959
$ 239.98
B
Thermostat
800164
$
14.26
B
Gasket
12-302
$
69.10
A
Contactor
13-205
$
81.48
A
High Limit
14-104
$
34.96 C12-5 Pressure Switch
COATES ELECTRIC HEATERS
Coates Heater Company manufactures the largest, most complete selection of electric heaters for
pools and spas. Great for commercial applications. All Coates models feature a stainless steel tank
for long life and corrosion resistance. Available in single phase & three phase configurations.
COATES 208-12
$ 4,291.46
C
208V 12KW 3 Phase
COATES 208-15
$ 4,367.20
C
208V 15KW 3 Phase
COATES 208-18
$ 4,737.54
C
208V 18KW 3 Phase
COATES 240-11
$ 1,511.54
C
240V 11KW Single Phase
COATES PARTS
20006036
$ 519.20
B
Element, 6KW 208V
20006046
$ 519.20
B
Element, 6KW 240V
20006029
$ 535.02
B
Element, 9KW 208V
20006009
$ 578.98
B
Element, 9KW 240V
20006609
$ 535.02
B
Element, 9KW 600V
20006039
$ 535.02
B
Element, 12KW 240V
20006612
$ 578.98
B
Element, 12KW 600V
20006615
$ 578.98
B
Element, 15KW 600V
21000100
$
34.68
B
Contactor, 50AMP, 240V
21000650
$
26.92
B
Contactor, 35AMP, 240V
22002001
$ 141.18
B
Temperature Control
22007210
$
59.78
B
Pressure Switch
22003820
$ 137.86
B
High Limit, Manual Reset
23000102
$ 290.60
B
Flow Switch
ELE-55F-R
13-205
20006612
20006009
22003820
22007210
20006039
600959
