RAINBOW FILTERS & P ARTS
RDC INLINE FILTER
Part Number ........... Description ..................................................................List Price Code
172425 ................... RDC Complete Filter,1½ FPT 18” top to bottom .........$ 156.52 A
172426F ................. RDC Complete Filter,1½ Slip Socket ..........................$ 155.90 A
18” top to bottom
1 17-2226 .................. Bypass Assembly........................................................$ 5.12 A
2 172224X ................. Drain Vent ...................................................................$ 7.02 A
3 17-2221 .................. Drain Vent O-Ring.......................................................$ 1.34 A
4 172213XT............... 1½” FPT Filter Manifold...............................................$ 30.26 A
4 17-2213P................ 1½”Slip Manifold Top...................................................$ 41.34 A
5 172232X ................. Gasket Support Ring...................................................$ 1.88 A
6 17-2222 .................. Cartridge Gasket.........................................................$ 3.38 A
7 C-4326.................... Cartridge, 3 oz ............................................................$ 30.64 A16-5
8 17-2223 .................. Lid O-Ring...................................................................$ 7.08 A
9 17-2212X................ Cartridge Housing - 14½” tall 6½” wide ......................$ 47.02 A
10 17-2214 .................. Lock Ring ....................................................................$ 20.88 A
DSF SKIM FILTER
Part Number ........... Description ..................................................................List Price Code
* 17-2554 .................. DSF 35 Skim Filter.....................................................$ 210.00 A
* 17-2551 .................. DSF 50 Skim Filter.....................................................$ 249.46 A
* NOTE: Complete filter requires ** 172555WH / 172555DG
1 17-2468 .................. Cover ..........................................................................$ 9.86 A
2 17-2467 .................. Skimmer Basket..........................................................$ 7.02 A
3 17-2466 .................. Diverter Plate Assembly..............................................$ 23.12 A
4 17-2465 .................. Cartridge Plug, Skim Filter ..........................................$ 6.80 A
5 M-4302 ................... Cartridge (DSF 35)......................................................$ 53.02 A16-5
5 M-4306 ................... Cartridge (DSF 50)......................................................$ 68.48 A16-5
6 17-2608 .................. Cartridge Puller ...........................................................$ 6.80 A
7 17-2226 .................. Bypass Assembly........................................................$ 5.12 A
8 17-2470 .................. Gasket.........................................................................$ 7.02 A
9 17-2469 ..................Weir.............................................................................$ 11.64 A
A 17-2480 .................. 90° Elbow....................................................................$ 11.26 A
B 17-2479 .................. Vac Plate.....................................................................$ 7.02 A
17-2392 .................. Drain Plug (earlier models) .........................................$ 7.02 A
17-2393 .................. Drain Plug O-Ring (earlier models).............................$ 5.02 A
17-2014 .................. Cartridge Plug .............................................................$ 2.90 A
** 172555WH.................. Face Plate Mounting Kit - White .................................$ 49.36 A
** 172555DG .................. Face Plate Mounting Kit - Dark Grey ..........................$ 49.36 A
Kits come with only 2 gaskets
4
1
RDC COMPLETE
DSF COMPLETE
3
8
9
10
6
5
2 3
4
6
7
5
1
2
3
4
5
5
7
A
B
6
8
8(x2)
9
17-2555WH
17-2555DG
