Refrigeration
UL & cUL listed (File # SA6300)
Coaxial Condensers
Superior Performance At An Optimum Cost
Coaxial water cooled condensers of various configurations are available. These
counter flow condensers provide good performance at a minimum cost. Also
available in copper and cupro-nickel. All coaxial condensers come complete
with brackets.
Part #
Tons
Refrig.
Connections
Water
Connections
Overall Dimensions Weight
(lbs.)
In
Out
In Out
H L W
47-5027-S
1/3
3/8" ID 3/8" ID
1/2" ID 1/2" ID
3"
9 1/4" 6 1/2"
3.0
47-5027-N
3.0
47-5028-S
1/2
3 7/8"
5.0
47-5028-N
5.0
47-5022-S
3/4
4 3/4"
10.0
47-5022-N
10.0
47-5023-S
1
5"
11" 8 1/2"
12.0
47-5023-N
12.0
47-5024-S
1 1/2
5/8" ID 5/8" ID
4 1/4"
11 3/4" 10"
14.0
47-5024-N
14.0
47-5025-S
2
1/2" ID 1/2" ID
5 1/4"
17.0
47-5025-N
17.0
47-5026-S
3
6 1/2" 12 7/8"
12"
27.0
47-5026-N
27.0
47-6209-S
5
7/8" ID 7/8" ID 10 1/2" 14"
54.0
47-6209-N
54.0
47-8267-S
1 1/4" SAE
Flare
1/4" SAE
Flare
1/2" ID
3/8"
NPT
8"
11" 7 3/4"
11
47-8238-S
2
9.75"
16
Dimensions subject to change without notice. • Copper outer tube available on special order.
S - Steel outer tube and copper inner tube. • N - Steel outer tube and 90-10 cupronickel inner tube.
Accumulators & Accumulator-Driers
Accumulator
Part #
Accumulator-Drier
Part #
"A"
ID
"B"
ID
"C"
Length
Weight
(lbs.)
49-620A 49-620
3/8"
3/8"
12"
0.8
49-621A 49-621
1/2"
0.8
49-622A 49-622
1/2"
0.8
49-623A 49-623
5/8"
0.8
49-624A 49-624
3/8"
3/8"
9"
0.6
49-625A 49-625
1/2"
0.6
46-626A 46-626
1/2"
0.6
Accumulators & Accumulator-Driers
Accumulators & Accumulator-Driers
All of the accumulators shown have 1 5/8" diameter
copper shells. Shell dimensions of the accumulator-
driers are the same as the accumulators, the only
difference being that the accumulator-driers contain
our monel wire cloth desiccant bag of 22 grams of
silica gel.
Accumulators and accumulator-driers may be mounted
slightly inclined, horizontally or vertically.
Sight Glasses
Bull’s Eye Sight Glasses
Regular and moisture-indicating sight glasses
provide a full view of the refrigerant level at
all times. The sight glasses are plated steel
with 5/16" diameter polyethylene floating ball.
Sight glasses must be sealed with Loctite
refrigerant sealer around the 1/2"- 14 NPT
thread.
Sight Glasses
Part #
Description
49-1523
Regular sight glass
49-1536
Moisture indicating sight glass.
49-7690
Prism sight glass (eliminates need for
polyethylene floating ball)
Tecumseh
Replacements
47-8267-S (Tecumseh 50812)
47-8238-S (Tecumseh 50827)
47-5024-S
Illustrated
49-1523
Not Exactly As Illustrated
47-8267-S
Illustrated
Coaxial Condensers
