Butt’s Pumps and Motors - page 1440

7
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
www.rotom.ca
115 & 230 Volts 1550 &1500 RPM
• Cast Iron (except R5109)
Part # Watts Amps Volts Rot RPM A Dim Shaft Comment Fig
O4-R5090
2
0.25 115 CW 1550 2.70" Hubless CAST IRON 2 WATT CONDENSER MOTOR 1
O4-R5109 0.25 115 CW 1550 2.50" Hubless GE 5109, WR60X77, 5KSM51AG3070,
5KSP51AZL826 1
O4-R5211
4
0.35 115 CW 1550 2.58" Hubless TECUMSEH TFM41, G.E. 5211 5KSP51AL511 1
O4-R5212 0.35 115 CCW 1550 2.58" Hubless G.E. 5212, 5KSP51AL513 1
O4-R5221 0.20 230 CW 1550 2.58" Hubless G.E. 5221, 5KSP51AL512, COPELAND 050-0246-00 1
O4-R5222 0.20 230 CW 1550 2.58" Hubless G.E. 5222, 5KSP51AL514 1
O4-R5911 5
0.35 115 CW 1550 3.30" Hubless COPELAND 050-0010-00,0178-00 050-0246-01,HILL
PP7577 1
O4-R6247 0.35 115 CW 1550 3.44" Hubless R CORNELIUS 1
O4-R5311
6
0.50 115 CW 1550 2.83" Hubless G.E. 5311, 5KSP51CL501, TECUMSEH TFM61 1
O4-R5312 0.50 115 CCW 1550 2.83" Hubless 5914767, 5914782, G.E. 5312, 5KSP51CL502 1
O4-R6243 0.50 115 CW 1550 3.44" Hubless CORNELIUS 1
O4-R5411
9
0.58 115 CW 1550 2.80" Hubless G.E. 5411, 5KSP51ECL551 TECUMSEH TFM91 1
O4-R5401 0.60 115 CW 1550 2.80" Hubless True 800401, All angle evaporator motor 1
O4-R5412 0.60 115 CCW 1550 3.40" Hubless G.E. 5412, 5KSP51ECL553 1
O4-R5421 0.30 230 CW 1550 2.83" Hubless TECUMSEH TFM62, TFM92, G.E. 5421,
5KSP51ECL552 1
O4-R5422 0.30 230 CCW 1550 2.83" Hubless G.E. 5422, 5KSP51ECL554 1
O4-R5611 0.60 115 CW 1550 3.07" Hubless HUSSMANN 47000, 58698 1
O4-R5612 0.60 115 CCW 1550 3.07" Hubless HUSSMANN 38360 1
O4-R6273 0.60 115 CW 1550 3.13" Hubless CONDENSER MOTOR FOR CAN TYPE VENDING MA-
CHINES 1
Fig.1
Note: Motors may be converted to shaft
type by using shaft adapter #92-A8110
51 Frame Unit Bearing Motors
3.5" Diameter - 51 Frame - Totally Enclosed
Morrill / EMS Replacements
