USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
Submersible Non-Clog Pumps
3
C
Professional Plumbing
Series SE-411/421
2" Spherical Solids Handling
Manual & Automatic
DISCHARGE .............................
2” NPT, Female, Vertical
LIQUID TEMPERATURE ..........SE411:
77°F (25°C) Continuous
SE421:
104°F (40°C) Continuous
VOLUTE.....................................
Cast Iron ASTM A-48, Class 30
MOTOR HOUSING ....................
Cast Iron ASTM A-48, Class 30
SEAL PLATE ............................
Cast Iron ASTM A-48, Class 30
IMPELLER:
Design
................
2 Vane, Open with pump out vanes on back side
Dynamically Balanced, ISO G6.3
Material
.............
Cast Iron ASTM A-48, Class 30
SHAFT
......................................
416 Stainless Steel
SQUARE RINGS .......................
Buna-N
HARDWARE ..............................
300 Series Stainless Steel
PAINT .........................................
Air Dry Enamel
SEAL:
Design
..............
Single Mechanical, Oil Filled Reservoir,
Secondary Exclusion Seal
Material
..............
Carbon/Ceramic/Buna-N
Hardware - 300 Series Stainless
CORD ENTRY ...........................
15 ft. (5m) Quick Disconnect Cord with plug On 115
Volt, Pressure Gromment for sealing and strain relief
UPPER BEARING......................
Single Row, Ball, Oil Lubricated
LOWER BEARING.....................
Single Row, Ball, Oil Lubricated
MOTOR:
Design
...............
NEMA L Torque Curve, Oil Filled, Squirrel Cage
Induction
Insulation
..........
Class B
SINGLE PHASE.........................
Permanent Split Capacitor (PSC)
Includes Overload Protection in Motor
LEVEL CONTROL ....................."A" -
Wide Angle, PVC, Mechanical, 15 ft (5m) cord
with Piggy-Back Plug, N/O
VF" -
Vertical Float, PVC, Snap Action, 15 ft (5m)
cord, with Piggy-Back plug. OFF point ONLY is
adjustable
OPTIONAL EQUIPMENT ...........
Seal Material, Additional Cord
Series: SE
(SE411 & SE421)
.4HP, 1750RPM, 60Hz
DESCRIPTION:
SUBMERSIBLE NON-CLOG SEWAGE PUMP DESIGNED
FOR TYPICAL RAW SEWAGE APPLICATIONS
3/13
Testing is performed with
water specific gravity of 1.0
@ 68˚F (20˚C), other fluids
may vary performance
CSA 108
UL 778
LR16567
C US
