Submersible Non-Clog Pumps
9
D
Professional Plumbing
Testing is performed with
water specific gravity of 1.0
@ 68˚F (20˚C), other fluids
may vary performance
Series SE-SP
Simplex Sewage Package Systems
Un-Assembled
Series: SE411-SP, 60Hz
SE51-SP, 60Hz
DESCRIPTION:
SIMPLEX SYSTEMS (ONE PUMP) ARE GOOD FOR RESI-
DENCES AND SMALL INDUSTRIAL SEWAGE OR SUMP
APPLICATIONS. THEY ARE DESIGNED TO HANDLE
WASTES FROM LAVATORIES, LAUNDRY TUBS, FLOOR
DRAINS, WATER CLOSETS, ETC., AND WILL PUSH THE
WATER FROM BELOWGROUND UP TOWHERE NORMAL
DRAINAGE WILL HANDLE IT.
SE411-SP:
One - SE411, .4HP, 115 Volt, 60Hz
Heavy duty sewage pump. Rugged cast iron body and impeller
One - Level Control P/N: 101758
Mechanical switch molded inside of a waterproof float. Single
control turns pump on and off automatically.
One -
1830 Polyethylene Basin P/N: 076119
18" (457mm) Dia. x 30" (762mm) Deep, with 4" (102mm) Inlet Hole.
One - 4" (102mm) Flexible Pipe Fitting Inlet P/N: 076149
Super-tuff Sanoprene construction
One -
18S22 Steel Cover P/N: 076120
With black powder coating, 2" (51mm) vent and 2" (51mm)
Discharge and cord openings
One - 2" (51mm) Vertical Check Valve P/N: 066828
With hose adaptors and clamps
SE51-SP:
One - SE51, .5HP, 115 Volt, 60Hz
Heavy duty sewage pump. Rugged cast iron body and impeller
One - Vertical Level Control P/N: 093474
Vertical float, PVC, Snap action, 15 ft. (5m) cord w/Piggy-Back
plug. OFF point only is adjustable.
One -
1830 Polyethylene Basin P/N: 076119
18" (457mm) Dia. x 30" (762mm) Deep, with 4" (102mm) Inlet Hole.
One - 4" (102mm) Flexible Pipe Fitting Inlet P/N: 076149
Super-tuff Sanoprene construction
One -
18S22 Steel Cover P/N: 076120
With black powder coating, 2" (51mm) vent and 2" (51mm)
Discharge and cord openings
One - 2" (51mm) Vertical Check Valve P/N: 066828
With hose adaptors and clamps
NOTE: DISCHARGE PIPE NOT SUPPLIED.
Other accessories may be ordered separately.
