USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
Portable Submersible Pumps
1
I
Professional Plumbing
Series 70, 71, 125, 126
2" NPT Male Discharge
DISCHARGE ...............................
2” NPT, Male, Vertical
MOTOR SHELL ...........................
Stainless Steel
VOLUTE ......................................
Non-Metallic
IMPELLER ...................................
Non-Merallic
SHAFT
........................................
420 Stainless Steel
HARDWARE ................................
300 Series Stainless Steel
SEAL:
Design
....................
Double Mechanical, Oil Filled Reservoir
Material:
Stationary Face
.......
Silicon/Carbide, Pump End
Ceramic, Motor End
Rotating Face
..........
Carbon
Elastomer
...............
Buna-N
Hardware
...............
300 Series Stainless
CORD ENTRY..............................
50 ft. (15m) Cord with plug on 120 Volt
Models. Molded for strain relief and
compression seal
MOTOR:
Design
....................
NEMA Design L - Single Phase.
Completely Air-Filled, Squirrel Cage
Induction
SINGLE PHASE...........................
Capacitor Start and Run. Includes
Overload Protection in Motor
STRAINER ...................................
.25" (6mm) Openings, Non-Metallic,
Rubberized
LIFTING HANDLE........................
Non-Metallic
LIFTING ROPE ............................
3/8" (9.7mm) Polypropylene, 25 ft. (7.6m)
Series: 70, 71, 125, 126
.7 & 1.25HP, 3450RPM, 60Hz
DESCRIPTION:
The pumps are compact, lightweight units and highly por-
table. Designed specifically for use by contractors and utility
service personnel. These pumps can operate in up to 104°F
(40°C) temperature water. Before pumping fluids other than
water consult the factory, giving fluid, fluid temperature, spe-
cific gravity, viscosity, capacity in USGPM and total head and/
or pressure requirements, including friction loss through dis-
charge line, fittings, valves, etc.
1/13
CSA 108
UL 778
LR16567
C US
Testing is performed with
water specific gravity of 1.0
@ 68˚F (20˚C), other fluids
may vary performance
