163
Electrical
120V
• Blue Cable - Steel Braid
Part #
Watts/ft Power
Length Weight
75-H611050
6 120V 50' Box
3.0 lbs.
75-H611100*
6 120V 100' Truck Pack 9.0 lbs.
75-H611250
6 120V 250' Reel
17.0 lbs.
120V
• Blue Cable - Steel Braid - Black Jacket
Part #
Watts/ft Power
Length Weight
75-H612050
6 120V 50' Box
4.0 lbs.
75-H612100*
6 120V 100' Truck Pack 10.0 lbs.
75-H612250
6 120V 250' Reel
20.0 lbs.
75-H612500
6 120V 500' Reel
43.0 lbs.
75-H6121000
6 120V 1000' Reel
77.0 lbs.
240V
• Red Cable - Steel Braid - Black Jacket
75-H622050
6 240V 50' Box
4.0 lbs.
75-H622100*
6 240V 100' Truck Pack 10.0 lbs.
75-H622250
6 240V 250' Reel
20.0 lbs.
75-H622500
6 240V 500' Reel
43.0 lbs.
75-H6221000
6 240V 1000' Reel
77.0 lbs.
* 100' Truck Packs include (2) 75-H900, (1) 75-H903 & (1) 75-H910.
240V
• Red Cable - Steel Braid
75-H621050
6 240V 50' Box
3.0 lbs.
75-H621100*
6 240V 100' Truck Pack 9.0 lbs.
75-H621250
6 240V 250' Reel
17.0 lbs.
* 100' Truck Packs include (2) 75-H900, (1) 75-H903 & (1) 75-H910.
Self Regulating Heat Cable
KeepWet Areas From Freezing
With WinterGard Wet for tracing air
conditioner drain pans to prevent freezing
or gut tracing freezer drain lines to prevent
backup problems.
Protect Pipes
With WinterGard or
WinterGard Plus for freeze
protection of short & small
diameter piping. Pre-cut
lengths or custom cut lengths.
Applications
- Ideal freeze protection for pipes in
unheated attics, basements and garages.
- Use it for intake and drain lines, water
meters, outside pipes and taps.
Applications
- Ideal for residential & commercial
buildings.
- Use it to freeze protect water service &
fire protection systems.
- Roof & gutter de-icing.
WinterGard Heating Cable
• Economical solution for residential/ commercial pipes up
to 2" diameter and circuit length up to 250'.
• Dry applications only.
• Tough - steel braided.
WinterGard Plus Heating Cable
• Designed for more demanding residential/ commercial
with larger plastic or metal pipes with diameters up to 8"
and circuit lengths up to 250'.
• Dry applications only.
• Tough - steel braided.
WinterGard Wet Heating Cable
• The answer for freeze protection in wet or high moisture
residential/ commercial locations such as drain lines
with larger plastic or metal pipes. Suitable for pipe
diameters up to 8" and circuit lengths up to 1000'.
• Wet or dry applications.
• Tough - steel braided & waterproof outer jacket.
"Self Regulating"
Heating Tape
• Easy installation
• Won’t burn out
• Won’t overheat
• OK to overlap
• OK to insulate
• OK for plastic
• No thermostat required
• Cut to desired length
• Higher efficiency
• UL & CSA approved
****WinterGardWet ***WinterGard Plus
**
WinterGard
18 AWG
BusWires
Conductive
Core
Tinned
Copper Braid***
Insulating
Jacket
**
Waterproof
Outer Jacket****
Raychem
Heat Cable
