169
Electrical
Potential Relays
Wiring
Diagram
Motor
Common
Line
Motor Start
Winding
Capacitor
Potential Relays
• Universal Replacements
• Dual Heavy Duty Contacts
• Universal Mounting Plate
Part #
Relay
Type
Continuous
Coil Voltage
Pick-up Drop Out
Range
Min Max
22-19002
63
170
140 153
65
22-19003
64
395
245 275 140
22-19004
65
336
171 184
90
22-19005
66
395
208 239 130
22-19006
67
420
300 328 121
22-19007
68
495
323 352 135
22-19008
69
395
180 195 100
22-19009
70
256
278 306
77
22-19010
71
420
223 252 150
22-19003
Illustrated
Potential Relay Selection Guide
• Ignore the numbers or letters represented by the asterisks *.
• The key numbers and letters are shown in bold black.
• Find these numbers and letters as shown above and then find your match from the chart.
Part # Supco
ESSEX
R B M 1 2 8
* * 6 * * 6 * W
GE, Form & Group
3 A R R -
* 1 0 A U
22-19002
9063 11M, 21M, 22M, 62M
2J, 2K, 2L, 2M, 5N, 7J, 7K, 7L, 7M, 7N, 8L, 8M, 8N.
22-19003
9064 23-27A, 63-67A, 23-26B, 63-66B, 25C, 26C, 65C, 66C 3A, 3B, 3AV, 3AU, 4A, 4B, 6A, 6B, 6AV, 10A,10B, 10AU, 10AV, 14A, 14B, 16A.
22-19004
9065 22-24P, 62-64P, 23R, 24R, 63R, 64R, 64S
3P, 3R, 3AP, 5P, 5R, 5S, 5T, 13P, 19N, 22S, 10AP.
22-19005
9066 26U, 66U, 25V, 26V, 65V, 66V, 66W
3U, 3V, 3AT, 6U, 6V, 6W, 16U.
22-19006
9067 23C, 24C, 63C, 64C, 24-27D, 64-67D
3C, 3D, 3AA, 4C, 4D, 4BK, 6C, 6D, 6AA, 10C, 10D, 26A, 26B, 26C, 26D.
22-19007
9068
23E, 24E, 27E, 63E, 23-27F, 63F, 64F, 66F, 67F, 23G,
26G, 63G, 66G, 25H, 65H, 66H
3E, 3F, 3AB, 3AC, 4E, 4F, 4G, 6E, 6F, 6G, 10H, 10AB, 10AC, 26E, 26F, 26G,
26H, 27E, 27F, 27G.
22-19008
9069 26
3S, 3T, 10S, 10T, 10AS, 13S, 13T, 20S, 25S, 25T, 10AS.
22-19009
9070 23D, 63D
5B, 5C, 5D, 5AA, 8B, 8C, 8D, 27A, 27B, 27C.
22-19010
9071 71
6TV, 6TW, 10V, 16TV, 20V.
Klixon Hardstart Kit
Klixon 8 EA Hard Start Kit
Part # Amps
Voltage
Hp
25-32320
25
120/208/240 Effective to 71⁄2 Hp.
Features
• Non positional.
• Reduces starting current.
• Doubles or triples starting torque.
• Solves low voltage problems.
• Comes with mounting clip.
25-32320
Illustrated
Relays
