24
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Features
• 48Y Frame
• 5.5" Diameter
• Open Enclosure
• Mounting: Stud, Strap & Base
(Resilient Rings)
• 60 Hz
• Sleeve Bearing
• Shaft: 4.0" × 1/2"
• Reversible
• Permanent Split Capacitor (P.S.C.)
• 26" Coloured Electrical Leads
• 40°C Ambient
• Insulation Class B
• Thermally Protected
Cross Reference
Rotom HP Voltage AO Smith Diversitech Emerson Fasco Embraco GE Marathon UE Rotom
DD-3583
1/4 115
DL1026
WG840583 1863
D721
E201 3583 X000 533 R43583
DD-3584
1/4 208/230
D1026
WG840584 1971
D725
E202 3584 X001 530 R43584
DD-3585
1/3 115
DL1036
WG840585 1864
D727
E203 3585 X002 532 R43585
DD-3586
1/3 208/230
D1036
WG840586 1972
D923
E204 3586 X003 529 R43586
DD-3587
1/2 115
DL1056
WG840587 1865
D701
E205 3587 X004 531 R43587
DD-3588
1/2 208/230
D1056
WG840588 1973
D703
E206 3588 X005 528 R43588
DD-3589
3/4 115
DL1076
WG840589 8904
D728
E207 3589 X009 678 R43589
DD-3590
3/4 208/230
D1076
WG840590 8905
D729
E208 3590 X010 679 R43590
24 Month
Warranty
+
Direct DriveMotors
92-A8617
Torsion Flex Bracket 5.0"
and 5.5" Dia.
9" & 10" Bolt Circles
92-A8550 -
5" Diameter
92-A8555 -
5.5" Diameter
9" & 10" Bolt Circles
5.5" Diameter for
1/2 HP and above
92-A8556 -
9" Bolt Circle
92-A8557
-
10" Bolt
Circle HEAVY DUTY
115 & 208/230 Volt, 3 Speed, 1075 RPM, Reversible Rotation
Part # HP Volts Amps Cap. SPD/RPM Rot.
Body Bearing Shaft
DD-3583
1/4
115
4.8
5/370 3/1075
Rev
4.22"
Sleeve 1/2"×4.0"
DD-3584
1/4
208/230
2.0
5/370 3/1075
Rev
4.22"
Sleeve 1/2"×4.0"
DD-3585
1/3
115
5.5 7.5/370 3/1075
Rev
4.37"
Sleeve 1/2"×4.0"
DD-3586
1/3
208/230
2.8
5/370 3/1075
Rev
4.48"
Sleeve 1/2"×4.0"
DD-3587
1/2
115
7.5 10/370 3/1075
Rev
5.25"
Sleeve 1/2"×4.0"
DD-3588
1/2
208/230
3.6 10/370 3/1075
Rev
5.23"
Sleeve 1/2"×4.0"
DD-3589
3/4
115
10.2 15/370 3/1075
Rev
5.48"
Sleeve 1/2"×4.0"
DD-3590
3/4
208/230
5.5 10/370 3/1075
Rev
5.37"
Sleeve 1/2"×4.0"
Capacitor Not Included
