28
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Frame
Adapter
92-A4856
Converts 48 Frame
Motors to 56 Frame Motors
5.5" Diameter Fan Canopy Motors
Part # HP RPM Volts
Amps
230
Amps
460
Amps
575
AMB Shaft
Cap
Single Phase
M5-S1502
1/3
1/1075 200/230/460
3.20
1.60
70°C 3.6"×1/2"
5/440
M5-S1504
1/2
1/1075 200/230/460
4.00
2.00
70°C 3.6"×1/2"
7.5/440
M5-S1503
1/1075 200/230/460
4.00
2.00
70°C 3.6"×1/2"
7.5/440
M5-S1508
1/1075
575
1.50
60°C 3.6"×1/2"
7.5/440
M5-S1510
3/4
1/1075 200/230/460
4.60
2.30
70°C 3.6"×1/2"
20/370
M5-S1512
1/1075 200/230/460
4.60
2.30
70°C 3.5"×5/8"
20/370
M5-S1514*
1
1/1075 200/230/460
6.40
3.20
70°C 4.0"×5/8"
25/370
M5-S1516*
1/1075
575
2.20
60°C 4.0"×5/8"
25/370
M5-S1518*
1½
1/1075 200/230/460
7.00
3.50
70°C 4.0"×5/8"
25/370
Three Phase
M5-T1532
1/2
1/1140 200/230/460
3.00
1.50
70°C 3.5"×1/2"
-
M5-T1534
3/4
1/1140 200/230/460
4.00
2.00
70°C 4.0"×5/8"
-
M5-T1536
1/1140
575
1.50
60°C 4.0"×5/8"
-
M5-T1538*
1
1/1140 200/230/460
5.60
2.80
70°C 4.0"×5/8"
-
M5-T1539
1/1140
575
1.30
40°C 4.0"×5/8"
-
M5-T1540*
1/1140
575
2.30
2.30
60°C 4.0"×5/8"
-
M5-T1542*
1½
1/1120 200/230/460
5.80
2.90
70°C 4.0"×5/8"
-
* - Includes 92-A4856
Replacement For:
Addison, Bohn, Comfortaire,
Carrier, Keeprite, York
• Reversible • 48 Frame
• Auto Protection • Shaft 4 5/8" × 1/2"
• High Thrust Capacity • Heavy Duty
• 60°C or 70°C Ambient
• Ball Bearing
M5-S1512
Illustrated
5.5" Diameter • Single Phase • Lug Mounting • Semi Enclosed • Reversible
Ball Bearing • Auto Protection • 60°C Ambient • 4.0"×1/2" Shaft
Part #
HP RPM
Volts
Amps
Cross Ref
M5-S1507A
1/2
1/1075
200/230/460
3.60
HC43VL460/600
M5-S1506A
1/2
1/1075
575
1.40
HC43VE575
6.5" Diameter • Single Phase • 56 Frame • CCW Rotation • Open Drip
Ball Bearing • Auto Protection • PSC • 3.6" × 5/8" Shaft
Part #
HP RPM
Volts
Amps
Cross Ref
M5-S1453
1
1/1075
200/230/460
6.5
HC5ITE200/230/460
M5-S1455
1
1/1075
575
2.10
HC5ITE575
Three Phase • P56Z Frame • 208-230/460 & 575 Volt • 5/8" × 3 1/2" Shaft
Part #
HP RPM
Volts
Amps
Cross Ref
UE-H978
SPL
1140
200/230/460/575 5.5/2.3/3.4
HD52AK652
M5-S1507
Illustrated
M5-S1455
Illustrated
Condenser FanMotors
Fan Canopy Condenser Fan -
Replacements For: Carrier
