Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
115 & 208/230 Volts, 4 Speed, 1075 RPM, Reversible Rotation
Part #
HP Volts
Amps
Cap.
A Dim.
Bearing
Shaft
DD-034
1/4
115
3.6
5/370
3.40"
Sleeve
1/2"×6"
DD-044
208/230
1.7
5/370
3.40"
Sleeve
1/2"×6"
DD-035
1/3
115
5.0
10/370
4.30"
Ball
1/2"×6"
DD-045
208/230
2.3
10/370
4.30"
Sleeve
1/2"×6"
DD-036
1/2
115
7.6
10/370
4.85"
Ball
1/2"×6"
DD-046
208/230
3.8
10/370
4.85"
Sleeve
1/2"×6"
Capacitor Not Included
Features
• 48Y Frame
• 5.5" Diameter
• Open Enclosure
• Mounting: Flex
• 60 Hz
• Sleeve Bearing (except DD-035 &
DD-036 are Ball Bearing
• Shaft: 1/2" × 6"
• Reversible
• Permanent Split Capacitor (P.S.C.)
• 60" Coloured Electrical Leads
• 45°C (113°F) Ambient
• Insulation Class B
• Thermally Protected
Cross Reference
Rotom AO Smith Fasco GE Marathon UE
Rotom
DD-034
FML1026 D1730 3783 X034
752 R42034, R42419
DD-044
-
D1733 3784
-
-
R42449
DD-035
FML1036 D1731 3785 X035 753, 947 R42035, R42319
DD-045
FM1036 D1734 3786
-
-
R42349
DD-036
FML1056 D1732 3787 X036
754 R42036, R 42219
DD-046
FM1056 D1735 3788
-
-
R42249
DD-035
Illustrated
9" & 10"
Bolt
Circle
+
24 Month
Warranty
5.5" Direct Drive Motors
5.5" Flex Mount Direct Drive Motors
